TC280F

x
Technical Data
MODELS TC–280F
Chamber Sizes 14.1" / 360mm
15.1" / 385mm
Chamber Depth 2+3.7" / 145mm
Distance Between Seal Bars 11.8" / 300mm
Seal Bar Length 11.8" x 1/300mm
Vacuum Pump Capacity 6m3/h (1/2 hp)
Power / Amp 0.6kw / 4.4A
Voltage 110V / 1ph / 60Hz / 12amp
Machine Size
(L) x (W) x (H)
15" x 18" x 16"
380 x 457 x 406mm
Machine Weight 115 lbs. (52kg)

Specifications are subject to change without notice.

• Stainless Steel Construction
• Clear domed lid
• Bladder activated sealing
• PD-01 Digital Control Board
• Choice of seal:
• 6mm wide seal or
• 3mm seal with electric cut-off
Options:
• Gas Flush
• PNC-01 Computerized water-resistant control panel (IP-56, 12 programs with oil indicator)
• Voltage
• Stainless Steel Cart


Pallet Wrap Machines PWM -10

x

WP-Evolution PWM10

Ramp $300 in needed

Pallet Wrap Machines MH-FG

x

Pallet Wrapper MH-FG-2000A-MR

Ultravac 2100

x

If you’re faced with any of the above challenges, UltraSource’s Ultravac 2100 swing lid double chamber vacuum packaging machine is the solution for you. With more than 3,000 machines in use, the Ultravac 2100 is the best selling American made vacuum
chamber machine. It offers unrestricted packaging flexibility and delivers a host of value added benefits:

• Extending shelf life of fresh product. Vacuum packaging keeps products fresh and eliminates freezer burn.
• Consistent, trouble free, quality retail packaging, package after package. Pozi Pressure® radius surface sealing forces moisture and contaminants out of the seal area for a clean leak resistant package. (See illustration on reverse side.)
• Two year warranty. Clear proof of performance tested, trouble free operation.
• Greater volume per cycle. Up to 15,000 4”x6” packages per eight hour shift with Ultravac 2100’s large chamber area.
• Reduced loading time. Optional UltraSource patented precut knife system allows operator to extend pouches beyond the edge of the chamber for perfect bag/pouch trimming.
• Strong, durable, die cast aluminum. All major chamber components of the Ultravac 2100 are solid cast aluminum and last through cycle after cycle.
• A solution for troublesome applications. Virtually eliminate leakers and reworks with optional 10mm wide band seal.
• Modified atmosphere packaging Optional gas flush operation is available on all Ultravac 2100 machines.
• Readily available parts and service. Same day shipping available on all parts.

The Ultravac 2100 is available in two different sizes, 8” or 12” chamber depths, and several pump and chamber configurations to meet your specific production needs. All machines are equipped with air cooled rugged vacuum pumps. The 8” model is available with a 7.5, 10, or 12-hp pump. For larger sized products like hams, turkeys, large primal cuts, or cheese blocks, the 12” chamber depth is recommended and comes equipped with a 10-hp or 12-hp pump.

graph

Options:

• Gas flush
• Patented precut knife system
• 10mm wide band seal
• Inline vacuum filters to collect debris
and/or m oisture (for wet products)
• Mobile wheel kit
• Locking casters
• Herculite storage cover
• Digital control panel
— 10 savable programs
— Supervisor security feature
— Vacuum sensing control
— Quick stop
— Soft air pulse vent
cycle control
— Seal and hold times

ST10

x
• Programmable temperature control
• Simple push button cycle operation
• On/Off indicator light
• Easy access for cleaning and maintenance
• High performance insulation helps avoid heat loss
• Easy fill and drain tank
• Low energy consumption
Note – power requirements:
• 230/60Hz, 3-phase
• 50 amps (ST-10)


Technical Data
MODELS ST–10
Max. Product Height 12"/305mm
Immersion Platform Size 22.8"/580mm
13.7"/350mm
Immersion Depth 14"/355mm
Cycle Time Up to 15 minutes
Volume of Water 30 Gallons/100 Liters
Electrical Heating 12kw/32A
Voltage 230V/3ph/60Hz
Machine Size
L x W x H (H1)
30" x 40" x 48.5"(55")
762 x 1016 x 1232mm(1397mm)
Machine Weight 442 lbs / 200kg

Specifications are subject to change without notice.

VT400 / VT570 MAP Tray Sealers

x
• Heavy duty stainless steel construction
• Semi-automatic operation
• Automatic film advance and cutting system
• PNC-01 computerized water resistant control panel (IP 56)(12 programs with oil indicator)
• Printed film registration system
• Busch USA vacuum pump
Options:
• Single phase motor
• Pump size
• Voltage
• Custom sized machines available


Technical Data
MODEL VT–400 VT–570
Tray Sizes 7.7"/196mm
5.7"/145mm
7.7"/196mm
5.7"/145mm
Tray Height 3.5"/255mm 3.5"/255mm
Film Diameter (Maximum) 10"/90mm 10"/90mm
Film Width (Maximum) 19.6"/500mm 19.6"/500mm
Vacuum Pump Capacity 40m3/h(2 hp) 63m3/h(3 hp)
Voltage 230V/3ph/60Hz / 30amp 230V/3ph/60Hz / 10amp
Machine Size
LxWxH
47″x26″x60″
1185x649x1519mm
91.5"x52"x51"
2324x1320x1295mm
Machine Weight 760 lbs. / 345kg 990 lbs. / 450kg

Specifications are subject to change without notice.

VT109 Tray/Cup Sealer

x
• Auto/ Semi-Automatic Operation
• Sensor/ Counter Film Indexing
• Individual temp. controls
• Air pressure regulator
• Up to 10 cycles per min.
Options:
• Custom Tray/ Cup die set
• Floor stand


Manual tray sealer also available (VT-106)

Technical Data
MODEL VT–106 VT–109
Tray Size 7.7″/196mm
7.7″/196mm
Tray Height Adjustable 3.5″/90mm
Film Web (Maximum) 8.5″/216mm 8.5″/216mm
Voltage 110V/1ph/60hz 110V/1ph/60hz
Machine Size
(LxWxH)
14″ x 13″ x 12″
355mm x 330mm x 305mm
20″ x 14″ x 28″
508mm x 355mm x 711mm

Specifications are subject to change without notice.

BT800 / BT1000

x
• Stainless Steel Construction
• Water Cooled Bars
• Busch 300/12HP Pump
• Auto Exit Conveyor
• Water resistant electrical box
• Computerized Water Resistant Control Panel (20 Programs with Oil Indicator)
• 10 mm Wide Seals
• Bladder Activated Sealing
• Heavy Duty Casters
• Air Assist
• Overload Warning Indicator
• Oil Change Indicator
Options:
• Pump size
• Top & Bottom seal
• Booster
• Mechanical Knife Cut-Off
• Perforated System
• Voltage
• Exit Conveyor
• Custom sizes


Technical Data
MODEL BT–800 BT–1100
Chamber Sizes 35"/880mm
37"/936mm
53"/1350mm
37"/940mm
Chamber Depth 8"/200mm 10"/250mm
Distance Between Seal Bars 24.8"/655mm 33"/838mm
Seal Bar Length 31.5"x 2/800mm 43.3"x 2/1100mm
Vacuum Pump Capacity 200m3/h (8hp) 302m3/h (12hp)
Voltage 220V / 3ph / 60Hz / 35amp 220V / 3ph / 60Hz / 48amp
Machine Size
L x W x H
82"x49"x40"
2075x1232x1025mm
139"x52"x53"
3520x1310x1350mm
Machine Weight 1320 lbs. (600kg) 1980 lbs. (900kg)

Specifications are subject to change without notice.

NZ Series Vacuum Nozzle

x
• Heavy-duty stainless steel construction
• BUSCH vacuum pump (Except NV-600)
• Castors
• Foldable table
• Computerized water-resistant control panel (IP 56), 12 programs with oil indicator
• Water-resistant electrical box (IP 56)
Options:
• Bag holding clips
• Top and bottom seal
• Gas flush
• Sensor control
• Soft air
• Digital seal temperature control system
• Custom sizes available


Technical Data
MODELS NZ–600 NZ–1000 NZ–1500 NZ–2000 NZ–2500 NZ–3000
Seal Bar Length 23.6″/600mm 39.3″/1000mm 59″/1500mm 78.7″/2000mm 98.4″/2500mm 118″/3000mm
Vacuum Pump Capacity 6m3/h(1/2hp) 21m3/h(1-1/4hp) 21m3/h(1-1/4hp) 40m3/h(2hp) 40m3/h(2hp) 63m3/h(3hp)
Power / Amp .37kw/2.3A .75kw/6.5A .75kw/6.5A 1.1kw/7.5A 1.1kw/7.5A 1.5kw/9A
Voltage 110V/1ph/60Hz 110V/1ph/60Hz 110V/1ph/60Hz 230V/3ph/60Hz 230V/3ph/60Hz 230V/3ph/60Hz
Machine Size
L x W x H
28.5″x47.5″x59″
720x1210x1500
28.5″x47.5″x59″
720x1210x1500
28.5″x67.5″x59″
720x1710x1500
35.8″x87″x59″
910x2210x1500
35.8″x106.6″x59″
910x2710x1500
35.8″x126.3″x59″
910x3210x1500
Machine Weight 385lbs/175kg 396lbs/180kg 484lbs/220kg 616lbs/280kg 704lbs/320kg 880lbs/400kg

Specifications are subject to change without notice.

CV1000 / CV1200

x
Equipped with a conveyor belt, the CV series will operate in a semi-automatic or continuous operation, which increases output and reduces labor costs. Production line operation can be achieved by adding an in feed and exit conveyor table which can be adjusted to various angles, preventing product overflow. The conveyor belt can be easily washed down and the stainless steel chains conform to food sanitation requirements. Other standard features include a high efficiency Busch vacuum pump and a microprocessor controller able to store 12 programs in memory.

• Stainless steel construction
• Can be equipped with conveyor belt
• Automatic washing feature
• Stainless steel chain
• Busch vacuum pump
• Computerized water resistant control panel (IP 56)
Options:
• Dual Seal Bars
• Gas flush
• Voltage
• Vacuum Pump Size
• Sensor Control
• Custom sizes available


Technical Data
MODELS CV–1000 CV–1200
Seal Bar Length 41.4 inches / 1050 mm 41.4 inches / 1050 mm
Distance Between Seal Bars 18 inches / 460 mm 22″ / 550mm
Chamber Depth 7″ / 180 mm 8″ / 200 mm
Vacuum Pump Capacity 100m3/h 302m3/h
Cycle 3 ~ 5 cycles / min 3 ~ 5 cycles / min
Voltage 220V / 60Hz / 3ph ( / 20amp 220V / 60Hz / 3ph ( / 48amp
Machine Weight 990 lbs. / 450 kgs 1295 lbs. / 588 kgs

Specifications are subject to change without notice.

Double Chamber Series

x
• Stainless steel construction
• Flat chamber for easy cleaning
• Busch USA vacuum pumps
• PNC-1 Computerized water resistant control panel (IP 56) (except DC-530)
• PD-01 (DC-530)
• 10mm wide seal
• Bladder activated sealing
• High-density plastic filler plates
• Pump overload warning indicator
• Oil change indicator
• Heavy-duty casters
• Air assist
• Automatic lid transfer (DC-900)
Options:
• Single Phase motor available up to 100m3/h(5hp)
• Gas flush
• Top and bottom seal
• Chamber height
• Mechanical knife cut-off system
• Automatic lid transfer (DC-530/640/800/860)
• Voltage
• Pump size
• Gas flush
• Pump horsepower upgrade
• Top and bottom seal


Technical Data
MODELS DC–530 DC–640 DC–650 DC–800 DC–860 DC–900
Chamber Sizes 30"/760mm
23.6"/600mm
32"/808mm
29"/730mm
32.2"/818mm
35"/889mm
38.5"/980mm
31.1"/790mm
40.9"/1040mm
40.7"/1035mm
48"/1220mm
41"/1040mm
Chamber
Depth
7"/178mm 8"/200mm 8"/200mm 8"/200mm 10"/255mm 12"/305mm
Distance Between
Seal Bars
17″/430mm 22″/560mm 28″/715mm 24″/610mm 33″/838mm 35″/880mm
Seal Bar
Length
21.2"x4/540mm 25.2"x4/640mm 25.2"x4/640mm 31.5"x4/800mm 34.6"x4/880mm 39.3"x4/1000mm
Vacuum Pump
Capacity
40m3/h (2hp) 63m3/h (3hp) 100m3/h (5hp) 100m3/h (5hp) 302m3/h (12hp) 302m3/h (12hp)
Voltage 230V/3ph/60Hz / 9amp 230V/3ph/60Hz / 11amp 230V/3ph/60Hz / 18amp 230V/3ph/60Hz / 18amp 230V/3ph/60Hz / 42amp 230V/3ph/60Hz / 42amp
Machine Size
L x W x H
58"x34"x44"
1473x863x1117
62"x36"x44"
1575x915x1117
62"x40.3"x43.4"
1580x1025x1103
75"x42"x45"
1905x1066x1143
83"x51"x48"
2108x1295x1219
98"x52"x50"
2489x1320x1270
Machine Weight 657 lbs. (298kg) 908 lbs. (412kg) 1216 lbs. (552kg) 1195 lbs. (572kg) 2100 lbs. (955kg) 2332 lbs. (1060kg)

Specifications are subject to change without notice.

SC680 / SC800

x
• Stainless steel construction
• Busch USA vacuum pump
• Flat chamber for easy cleaning
• Bladder activated sealing
• PD-01 Digital Control Board
• Durable, removable aluminum cushion bars
• Air assist
• Choice of seal:
• 6mm seal wire or
• electric cut-off
Options:
• PNC-01 Computerized water resistant control panel (IP-56. 12 programs with oil indicator)
• Single Phase vacuum pump
• Gas Flush
• Pump horsepower upgrade
• Voltage
• Top and bottom seal
• Soft air
• Mechanical knife cut-off system


Technical Data
MODEL SC–420LR SC–520LR
Chamber Sizes 19.8"/505mm
19.2"/490mm
23.6"/600mm
23.6"/600mm
Chamber Height 5"+4"/75+230mm 3"+5"/75+200mm
Distance Between Seal Bars 14.5"/370mm 18"/450mm
Seal Bar Length 16.9"x 2/430mm 21.3"x 2/540mm
Vacuum Pump Capacity 21m3/h (1–1/4hp) 21m3/h (1–1/4hp)
Voltage 110V / 1ph / 60Hz / 16amp 110V / 1ph / 60Hz / 16amp
Machine Size
L x W x H
21"x22"x36"
522x552x916mm
24"x30"x36"
615x756x916mm
Machine Weight 234 lbs. (106kg) 310 lbs. (140kg)

Specifications are subject to change without notice.

SC420 / SC520

x
• Stainless steel construction
• BUSCH USA vacuum pump
• Bladder activated sealing
• PD-01 Digital Control Board
• Air assist
• Choice of seal:
• 6mm extra wide seal or
• Seal with electric cut-off
Options:
• PNC-01 Computerized water resistant control panel (IP-56, 12 programs with oil indicator)
• Gas Flush
• Voltage
• Top and bottom seal
• Soft air


Technical Data
MODEL SC–420LR SC–520LR
Chamber Sizes 19.8"/505mm
19.2"/490mm
23.6"/600mm
23.6"/600mm
Chamber Height 5"+4"/75+230mm 3"+5"/75+200mm
Distance Between Seal Bars 14.5"/370mm 18"/450mm
Seal Bar Length 16.9"x 2/430mm 21.3"x 2/540mm
Vacuum Pump Capacity 21m3/h (1–1/4hp) 21m3/h (1–1/4hp)
Voltage 110V / 1ph / 60Hz / 16amp 110V / 1ph / 60Hz / 16amp
Machine Size
L x W x H
21"x22"x36"
522x552x916mm
24"x30"x36"
615x756x916mm
Machine Weight 234 lbs. (106kg) 310 lbs. (140kg)

TC420 / TC520

x
• Stainless steel construction
• Busch Vacuum Pump
• Clear domed lid
• Bladder activated sealing
• PD-01 Digital Control Board
• Air regulator (TC-520)
• Choice of seal:
• 6mm wide seal or
• 3mm seal with electric cut-off
Options:
• PNC-01 Computerized water-resistant control panel (IP-56, 12 programs with oil indicator)
• Gas Flush
• Pump size
• Voltage
• Stainless steel cart
• Soft air


Technical Data
MODELS TC–420F TC–420LR TC–520F TC–520LR
Chamber Sizes 19.8" / 505mm
19.2" / 490mm
19.8" / 505mm
19.2" / 490mm
23.6" / 600mm
23.6" / 600mm
23.6" / 600mm
23.6" / 600mm
Chamber Depth 5"+4" / 75+105mm 5"+4" / 75+105mm 3"+5" / 75+105mm 3"+5" / 75+105mm
Distance Between
Seal Bars
17" / 430mm 14.5" / 370mm 20" / 505mm 18" / 450mm
Seal Bar Length 17.7 x 1/450mm 16.9 x 2/430mm 21.2 x 1/540mm 21.2 x 2/540mm
Vacuum Pump Capacity 21m3/h (1–1/4 hp) 21m3/h (1–1/4 hp) 21m3/h (1–1/4 hp) 21m3/h (1–1/4 hp)
Voltage 110V / 1ph / 60Hz / 16amp 110V / 1ph / 60Hz / 16amp 110V / 1ph / 60Hz / 16amp 110V / 1ph / 60Hz / 16amp
Machine Size
(L) x (W) x (H)
20" x 21" x 21"
508 x 533 x 533mm
20" x 21" x 21"
508 x 533 x 533mm
24" x 30" x 22"
610 x 762 x 558mm
24" x 30" x 22"
610 x 762 x 558mm
Machine Weight 220 lbs. (100kg) 220 lbs. (100kg) 280 lbs. (127kg) 280 lbs. (127kg)

TC350

x
Technical Data
MODEL TC–350FLR
Chamber Sizes 41.4" / 1050mm
16.6" / 422mm
Chamber Depth 4.7" / 120mm
Seal Bar Length 32.8 x 1/835mm
14.1" x 2/360mm
Vacuum Pump Capacity 21m3/h (1–1/4 hp)
Voltage 110V / 1ph / 60Hz / 16amp
Machine Size
(L) x (W) x (H)
42" x 19" x 17"
1066 x 482 x 430mm
Machine Weight 253 lbs. (115kg)
• PD-01 Digital Control Panel
• Stainless steel construction
• Clear see-through lid
• Bladder activated sealing
• Water-resistant electrical box (IP-56)
• BUSCH vacuum pump
• 6mm seal wire
• Air Assist
• Filler plates
• Seal bar selector (front/sides/all)
Options:
• PNC-01 Computerized water-resistant control panel (IP-56, 12 programs with oil indicator)
• Voltage
• Gas Flush
• Floor Stan[


TC280F
Table Top Vacuum Machine
Pallet Wrap Machines PWM -10
WP-Evolution PWM10 Ramp $300 in needed
Pallet Wrap Machines MH-FG
Pallet Wrapper MH-FG-2000A-MR
Ultravac 2100
Increase Production Efficiencies
ST700
Hot Water Shrink Tank
ST10
Hot Water Shrink Tank
VT400 / VT570 MAP Tray Sealers
Map Tray Sealers
VT109 Tray/Cup Sealer
Tray & Cup Sealer
BT800 / BT1000
Belt Type Vacuum Sealer
NZ Series Vacuum Nozzle
Nozzle Type Vacuum Packaging
CV1000 / CV1200
Continues Vacuum Packaging Machine
Double Chamber Series
Vacuum Pack Bags & More
SC680 / SC800
Single Chamber Vacuum Packaging
SC420 / SC520
Single Chamber Vacuum Packaging
TC420 / TC520
Table Top Vacuum Machine
TC350
Table Top Vacuum Machine
If you have any questions, please do not hesitate to call us at (909) 373-5807 or email us at info@raycocorp.com. We will help you find the right equipment whether the equipment is on our website or in our warehouse.
Equipment For Sale Price Click For More Details
UnderConstruction

Click for More Details
ANCHOR SANDWICH PACKAGING MACHINE

$ 7500.00 Click for More Details
KOCH/RUHLE SR3 DICER w/FEED CONVEYOR

200,000 Click for More Details
GRASSELLI RST520 MEMBRANE SKINNER

$ 12900.00 Click for More Details
BRIDGE TR12 POULTRY FLATTNER

9500.00 Click for More Details
TRICLOVER PUMP W/5hp Vari Drive

$ 4900.00 Click for More Details
Double Chamber Vacuum Packaging Machine 2100A

$8900.00 Click for More Details
IQF LINE FOR FROZEN SHRIMP OR

$190,000.00 Click for More Details
500lb Mixers All Stainless Hydraulic

$5500.00 Click for More Details
Urschel CC-D Cheese Shredder 5hp – $17500 (TBD)

$17,500 Click for More Details
VERTICAL FORM,FILL AND SEAL FOR 5″ WIDE FINISHED BAG

$12,500 Click for More Details
CHORIZO GRINDING LINE

$59,000 Click for More Details
nsf food packaging equipment

Click for More Details
Vacuum Packing Machine Equipment & Supplies

Click for More Details


Rayco values our vendor relationships that have made it possible to offer only the highest quality products at affordable prices. All supplies are FDA approved for direct contact with food. A few of the supplies offered to you are

-Film (clear or printed with your company information and logo),
-3-mil and 4-mil vacuum pouches; converted from co-extruded cast film for superior clarity and performance.
-Boilable Vacuum Pouches
-Zipper Vacuum Pouches
-Safe-Handling Vacuum Pouches
-Poly Bags
-Jerky Bag

NEW AND USED
TABLE-TOP
SINGLE CHAMBER
DOUBLE CHAMBER
VACUUM PACKAGING MACHINES
ALL MAKES & MODELS
KOCH ULTRAVACS
MINI-PACK
PROMARKS

CONTACT RANDY @ (909) 373-5807 Process and Packaging Specialist

MEAT GRINDERS-MEAT MIXERS-MEAT SAWS
VACUUM TUMBLERS-MEAT TENDERIZERS
SLICERS-DICERS-INJECTORS-BOWL CHOPPER
CUSTOM CONVEYORS-INCLINE SCREW
BUCKET ELEVATORS-VIBRATING TRANSFER
VERTICAL FORM FILL & SEAL
COMBINATION SCALES

MACHINE INSPECTION AND APPRISALS

TC280F

x
Technical Data
MODELS TC–280F
Chamber Sizes 14.1" / 360mm
15.1" / 385mm
Chamber Depth 2+3.7" / 145mm
Distance Between Seal Bars 11.8" / 300mm
Seal Bar Length 11.8" x 1/300mm
Vacuum Pump Capacity 6m3/h (1/2 hp)
Power / Amp 0.6kw / 4.4A
Voltage 110V / 1ph / 60Hz / 12amp
Machine Size
(L) x (W) x (H)
15" x 18" x 16"
380 x 457 x 406mm
Machine Weight 115 lbs. (52kg)

Specifications are subject to change without notice.

• Stainless Steel Construction
• Clear domed lid
• Bladder activated sealing
• PD-01 Digital Control Board
• Choice of seal:
• 6mm wide seal or
• 3mm seal with electric cut-off
Options:
• Gas Flush
• PNC-01 Computerized water-resistant control panel (IP-56, 12 programs with oil indicator)
• Voltage
• Stainless Steel Cart


Pallet Wrap Machines PWM -10

x

WP-Evolution PWM10

Ramp $300 in needed

Pallet Wrap Machines MH-FG

x

Pallet Wrapper MH-FG-2000A-MR

Ultravac 2100

x

If you’re faced with any of the above challenges, UltraSource’s Ultravac 2100 swing lid double chamber vacuum packaging machine is the solution for you. With more than 3,000 machines in use, the Ultravac 2100 is the best selling American made vacuum
chamber machine. It offers unrestricted packaging flexibility and delivers a host of value added benefits:

• Extending shelf life of fresh product. Vacuum packaging keeps products fresh and eliminates freezer burn.
• Consistent, trouble free, quality retail packaging, package after package. Pozi Pressure® radius surface sealing forces moisture and contaminants out of the seal area for a clean leak resistant package. (See illustration on reverse side.)
• Two year warranty. Clear proof of performance tested, trouble free operation.
• Greater volume per cycle. Up to 15,000 4”x6” packages per eight hour shift with Ultravac 2100’s large chamber area.
• Reduced loading time. Optional UltraSource patented precut knife system allows operator to extend pouches beyond the edge of the chamber for perfect bag/pouch trimming.
• Strong, durable, die cast aluminum. All major chamber components of the Ultravac 2100 are solid cast aluminum and last through cycle after cycle.
• A solution for troublesome applications. Virtually eliminate leakers and reworks with optional 10mm wide band seal.
• Modified atmosphere packaging Optional gas flush operation is available on all Ultravac 2100 machines.
• Readily available parts and service. Same day shipping available on all parts.

The Ultravac 2100 is available in two different sizes, 8” or 12” chamber depths, and several pump and chamber configurations to meet your specific production needs. All machines are equipped with air cooled rugged vacuum pumps. The 8” model is available with a 7.5, 10, or 12-hp pump. For larger sized products like hams, turkeys, large primal cuts, or cheese blocks, the 12” chamber depth is recommended and comes equipped with a 10-hp or 12-hp pump.

graph

Options:

• Gas flush
• Patented precut knife system
• 10mm wide band seal
• Inline vacuum filters to collect debris
and/or m oisture (for wet products)
• Mobile wheel kit
• Locking casters
• Herculite storage cover
• Digital control panel
— 10 savable programs
— Supervisor security feature
— Vacuum sensing control
— Quick stop
— Soft air pulse vent
cycle control
— Seal and hold times

ST10

x
• Programmable temperature control
• Simple push button cycle operation
• On/Off indicator light
• Easy access for cleaning and maintenance
• High performance insulation helps avoid heat loss
• Easy fill and drain tank
• Low energy consumption
Note – power requirements:
• 230/60Hz, 3-phase
• 50 amps (ST-10)


Technical Data
MODELS ST–10
Max. Product Height 12"/305mm
Immersion Platform Size 22.8"/580mm
13.7"/350mm
Immersion Depth 14"/355mm
Cycle Time Up to 15 minutes
Volume of Water 30 Gallons/100 Liters
Electrical Heating 12kw/32A
Voltage 230V/3ph/60Hz
Machine Size
L x W x H (H1)
30" x 40" x 48.5"(55")
762 x 1016 x 1232mm(1397mm)
Machine Weight 442 lbs / 200kg

Specifications are subject to change without notice.

VT400 / VT570 MAP Tray Sealers

x
• Heavy duty stainless steel construction
• Semi-automatic operation
• Automatic film advance and cutting system
• PNC-01 computerized water resistant control panel (IP 56)(12 programs with oil indicator)
• Printed film registration system
• Busch USA vacuum pump
Options:
• Single phase motor
• Pump size
• Voltage
• Custom sized machines available


Technical Data
MODEL VT–400 VT–570
Tray Sizes 7.7"/196mm
5.7"/145mm
7.7"/196mm
5.7"/145mm
Tray Height 3.5"/255mm 3.5"/255mm
Film Diameter (Maximum) 10"/90mm 10"/90mm
Film Width (Maximum) 19.6"/500mm 19.6"/500mm
Vacuum Pump Capacity 40m3/h(2 hp) 63m3/h(3 hp)
Voltage 230V/3ph/60Hz / 30amp 230V/3ph/60Hz / 10amp
Machine Size
LxWxH
47″x26″x60″
1185x649x1519mm
91.5"x52"x51"
2324x1320x1295mm
Machine Weight 760 lbs. / 345kg 990 lbs. / 450kg

Specifications are subject to change without notice.

VT109 Tray/Cup Sealer

x
• Auto/ Semi-Automatic Operation
• Sensor/ Counter Film Indexing
• Individual temp. controls
• Air pressure regulator
• Up to 10 cycles per min.
Options:
• Custom Tray/ Cup die set
• Floor stand


Manual tray sealer also available (VT-106)

Technical Data
MODEL VT–106 VT–109
Tray Size 7.7″/196mm
7.7″/196mm
Tray Height Adjustable 3.5″/90mm
Film Web (Maximum) 8.5″/216mm 8.5″/216mm
Voltage 110V/1ph/60hz 110V/1ph/60hz
Machine Size
(LxWxH)
14″ x 13″ x 12″
355mm x 330mm x 305mm
20″ x 14″ x 28″
508mm x 355mm x 711mm

Specifications are subject to change without notice.

BT800 / BT1000

x
• Stainless Steel Construction
• Water Cooled Bars
• Busch 300/12HP Pump
• Auto Exit Conveyor
• Water resistant electrical box
• Computerized Water Resistant Control Panel (20 Programs with Oil Indicator)
• 10 mm Wide Seals
• Bladder Activated Sealing
• Heavy Duty Casters
• Air Assist
• Overload Warning Indicator
• Oil Change Indicator
Options:
• Pump size
• Top & Bottom seal
• Booster
• Mechanical Knife Cut-Off
• Perforated System
• Voltage
• Exit Conveyor
• Custom sizes


Technical Data
MODEL BT–800 BT–1100
Chamber Sizes 35"/880mm
37"/936mm
53"/1350mm
37"/940mm
Chamber Depth 8"/200mm 10"/250mm
Distance Between Seal Bars 24.8"/655mm 33"/838mm
Seal Bar Length 31.5"x 2/800mm 43.3"x 2/1100mm
Vacuum Pump Capacity 200m3/h (8hp) 302m3/h (12hp)
Voltage 220V / 3ph / 60Hz / 35amp 220V / 3ph / 60Hz / 48amp
Machine Size
L x W x H
82"x49"x40"
2075x1232x1025mm
139"x52"x53"
3520x1310x1350mm
Machine Weight 1320 lbs. (600kg) 1980 lbs. (900kg)

Specifications are subject to change without notice.

NZ Series Vacuum Nozzle

x
• Heavy-duty stainless steel construction
• BUSCH vacuum pump (Except NV-600)
• Castors
• Foldable table
• Computerized water-resistant control panel (IP 56), 12 programs with oil indicator
• Water-resistant electrical box (IP 56)
Options:
• Bag holding clips
• Top and bottom seal
• Gas flush
• Sensor control
• Soft air
• Digital seal temperature control system
• Custom sizes available


Technical Data
MODELS NZ–600 NZ–1000 NZ–1500 NZ–2000 NZ–2500 NZ–3000
Seal Bar Length 23.6″/600mm 39.3″/1000mm 59″/1500mm 78.7″/2000mm 98.4″/2500mm 118″/3000mm
Vacuum Pump Capacity 6m3/h(1/2hp) 21m3/h(1-1/4hp) 21m3/h(1-1/4hp) 40m3/h(2hp) 40m3/h(2hp) 63m3/h(3hp)
Power / Amp .37kw/2.3A .75kw/6.5A .75kw/6.5A 1.1kw/7.5A 1.1kw/7.5A 1.5kw/9A
Voltage 110V/1ph/60Hz 110V/1ph/60Hz 110V/1ph/60Hz 230V/3ph/60Hz 230V/3ph/60Hz 230V/3ph/60Hz
Machine Size
L x W x H
28.5″x47.5″x59″
720x1210x1500
28.5″x47.5″x59″
720x1210x1500
28.5″x67.5″x59″
720x1710x1500
35.8″x87″x59″
910x2210x1500
35.8″x106.6″x59″
910x2710x1500
35.8″x126.3″x59″
910x3210x1500
Machine Weight 385lbs/175kg 396lbs/180kg 484lbs/220kg 616lbs/280kg 704lbs/320kg 880lbs/400kg

Specifications are subject to change without notice.

CV1000 / CV1200

x
Equipped with a conveyor belt, the CV series will operate in a semi-automatic or continuous operation, which increases output and reduces labor costs. Production line operation can be achieved by adding an in feed and exit conveyor table which can be adjusted to various angles, preventing product overflow. The conveyor belt can be easily washed down and the stainless steel chains conform to food sanitation requirements. Other standard features include a high efficiency Busch vacuum pump and a microprocessor controller able to store 12 programs in memory.

• Stainless steel construction
• Can be equipped with conveyor belt
• Automatic washing feature
• Stainless steel chain
• Busch vacuum pump
• Computerized water resistant control panel (IP 56)
Options:
• Dual Seal Bars
• Gas flush
• Voltage
• Vacuum Pump Size
• Sensor Control
• Custom sizes available


Technical Data
MODELS CV–1000 CV–1200
Seal Bar Length 41.4 inches / 1050 mm 41.4 inches / 1050 mm
Distance Between Seal Bars 18 inches / 460 mm 22″ / 550mm
Chamber Depth 7″ / 180 mm 8″ / 200 mm
Vacuum Pump Capacity 100m3/h 302m3/h
Cycle 3 ~ 5 cycles / min 3 ~ 5 cycles / min
Voltage 220V / 60Hz / 3ph ( / 20amp 220V / 60Hz / 3ph ( / 48amp
Machine Weight 990 lbs. / 450 kgs 1295 lbs. / 588 kgs

Specifications are subject to change without notice.

Double Chamber Series

x
• Stainless steel construction
• Flat chamber for easy cleaning
• Busch USA vacuum pumps
• PNC-1 Computerized water resistant control panel (IP 56) (except DC-530)
• PD-01 (DC-530)
• 10mm wide seal
• Bladder activated sealing
• High-density plastic filler plates
• Pump overload warning indicator
• Oil change indicator
• Heavy-duty casters
• Air assist
• Automatic lid transfer (DC-900)
Options:
• Single Phase motor available up to 100m3/h(5hp)
• Gas flush
• Top and bottom seal
• Chamber height
• Mechanical knife cut-off system
• Automatic lid transfer (DC-530/640/800/860)
• Voltage
• Pump size
• Gas flush
• Pump horsepower upgrade
• Top and bottom seal


Technical Data
MODELS DC–530 DC–640 DC–650 DC–800 DC–860 DC–900
Chamber Sizes 30"/760mm
23.6"/600mm
32"/808mm
29"/730mm
32.2"/818mm
35"/889mm
38.5"/980mm
31.1"/790mm
40.9"/1040mm
40.7"/1035mm
48"/1220mm
41"/1040mm
Chamber
Depth
7"/178mm 8"/200mm 8"/200mm 8"/200mm 10"/255mm 12"/305mm
Distance Between
Seal Bars
17″/430mm 22″/560mm 28″/715mm 24″/610mm 33″/838mm 35″/880mm
Seal Bar
Length
21.2"x4/540mm 25.2"x4/640mm 25.2"x4/640mm 31.5"x4/800mm 34.6"x4/880mm 39.3"x4/1000mm
Vacuum Pump
Capacity
40m3/h (2hp) 63m3/h (3hp) 100m3/h (5hp) 100m3/h (5hp) 302m3/h (12hp) 302m3/h (12hp)
Voltage 230V/3ph/60Hz / 9amp 230V/3ph/60Hz / 11amp 230V/3ph/60Hz / 18amp 230V/3ph/60Hz / 18amp 230V/3ph/60Hz / 42amp 230V/3ph/60Hz / 42amp
Machine Size
L x W x H
58"x34"x44"
1473x863x1117
62"x36"x44"
1575x915x1117
62"x40.3"x43.4"
1580x1025x1103
75"x42"x45"
1905x1066x1143
83"x51"x48"
2108x1295x1219
98"x52"x50"
2489x1320x1270
Machine Weight 657 lbs. (298kg) 908 lbs. (412kg) 1216 lbs. (552kg) 1195 lbs. (572kg) 2100 lbs. (955kg) 2332 lbs. (1060kg)

Specifications are subject to change without notice.

SC680 / SC800

x
• Stainless steel construction
• Busch USA vacuum pump
• Flat chamber for easy cleaning
• Bladder activated sealing
• PD-01 Digital Control Board
• Durable, removable aluminum cushion bars
• Air assist
• Choice of seal:
• 6mm seal wire or
• electric cut-off
Options:
• PNC-01 Computerized water resistant control panel (IP-56. 12 programs with oil indicator)
• Single Phase vacuum pump
• Gas Flush
• Pump horsepower upgrade
• Voltage
• Top and bottom seal
• Soft air
• Mechanical knife cut-off system


Technical Data
MODEL SC–420LR SC–520LR
Chamber Sizes 19.8"/505mm
19.2"/490mm
23.6"/600mm
23.6"/600mm
Chamber Height 5"+4"/75+230mm 3"+5"/75+200mm
Distance Between Seal Bars 14.5"/370mm 18"/450mm
Seal Bar Length 16.9"x 2/430mm 21.3"x 2/540mm
Vacuum Pump Capacity 21m3/h (1–1/4hp) 21m3/h (1–1/4hp)
Voltage 110V / 1ph / 60Hz / 16amp 110V / 1ph / 60Hz / 16amp
Machine Size
L x W x H
21"x22"x36"
522x552x916mm
24"x30"x36"
615x756x916mm
Machine Weight 234 lbs. (106kg) 310 lbs. (140kg)

Specifications are subject to change without notice.

SC420 / SC520

x
• Stainless steel construction
• BUSCH USA vacuum pump
• Bladder activated sealing
• PD-01 Digital Control Board
• Air assist
• Choice of seal:
• 6mm extra wide seal or
• Seal with electric cut-off
Options:
• PNC-01 Computerized water resistant control panel (IP-56, 12 programs with oil indicator)
• Gas Flush
• Voltage
• Top and bottom seal
• Soft air


Technical Data
MODEL SC–420LR SC–520LR
Chamber Sizes 19.8"/505mm
19.2"/490mm
23.6"/600mm
23.6"/600mm
Chamber Height 5"+4"/75+230mm 3"+5"/75+200mm
Distance Between Seal Bars 14.5"/370mm 18"/450mm
Seal Bar Length 16.9"x 2/430mm 21.3"x 2/540mm
Vacuum Pump Capacity 21m3/h (1–1/4hp) 21m3/h (1–1/4hp)
Voltage 110V / 1ph / 60Hz / 16amp 110V / 1ph / 60Hz / 16amp
Machine Size
L x W x H
21"x22"x36"
522x552x916mm
24"x30"x36"
615x756x916mm
Machine Weight 234 lbs. (106kg) 310 lbs. (140kg)

TC420 / TC520

x
• Stainless steel construction
• Busch Vacuum Pump
• Clear domed lid
• Bladder activated sealing
• PD-01 Digital Control Board
• Air regulator (TC-520)
• Choice of seal:
• 6mm wide seal or
• 3mm seal with electric cut-off
Options:
• PNC-01 Computerized water-resistant control panel (IP-56, 12 programs with oil indicator)
• Gas Flush
• Pump size
• Voltage
• Stainless steel cart
• Soft air


Technical Data
MODELS TC–420F TC–420LR TC–520F TC–520LR
Chamber Sizes 19.8" / 505mm
19.2" / 490mm
19.8" / 505mm
19.2" / 490mm
23.6" / 600mm
23.6" / 600mm
23.6" / 600mm
23.6" / 600mm
Chamber Depth 5"+4" / 75+105mm 5"+4" / 75+105mm 3"+5" / 75+105mm 3"+5" / 75+105mm
Distance Between
Seal Bars
17" / 430mm 14.5" / 370mm 20" / 505mm 18" / 450mm
Seal Bar Length 17.7 x 1/450mm 16.9 x 2/430mm 21.2 x 1/540mm 21.2 x 2/540mm
Vacuum Pump Capacity 21m3/h (1–1/4 hp) 21m3/h (1–1/4 hp) 21m3/h (1–1/4 hp) 21m3/h (1–1/4 hp)
Voltage 110V / 1ph / 60Hz / 16amp 110V / 1ph / 60Hz / 16amp 110V / 1ph / 60Hz / 16amp 110V / 1ph / 60Hz / 16amp
Machine Size
(L) x (W) x (H)
20" x 21" x 21"
508 x 533 x 533mm
20" x 21" x 21"
508 x 533 x 533mm
24" x 30" x 22"
610 x 762 x 558mm
24" x 30" x 22"
610 x 762 x 558mm
Machine Weight 220 lbs. (100kg) 220 lbs. (100kg) 280 lbs. (127kg) 280 lbs. (127kg)

TC350

x
Technical Data
MODEL TC–350FLR
Chamber Sizes 41.4" / 1050mm
16.6" / 422mm
Chamber Depth 4.7" / 120mm
Seal Bar Length 32.8 x 1/835mm
14.1" x 2/360mm
Vacuum Pump Capacity 21m3/h (1–1/4 hp)
Voltage 110V / 1ph / 60Hz / 16amp
Machine Size
(L) x (W) x (H)
42" x 19" x 17"
1066 x 482 x 430mm
Machine Weight 253 lbs. (115kg)
• PD-01 Digital Control Panel
• Stainless steel construction
• Clear see-through lid
• Bladder activated sealing
• Water-resistant electrical box (IP-56)
• BUSCH vacuum pump
• 6mm seal wire
• Air Assist
• Filler plates
• Seal bar selector (front/sides/all)
Options:
• PNC-01 Computerized water-resistant control panel (IP-56, 12 programs with oil indicator)
• Voltage
• Gas Flush
• Floor Stan[


TC280F
Table Top Vacuum Machine
Pallet Wrap Machines PWM -10
WP-Evolution PWM10 Ramp $300 in needed
Pallet Wrap Machines MH-FG
Pallet Wrapper MH-FG-2000A-MR
Ultravac 2100
Increase Production Efficiencies
ST700
Hot Water Shrink Tank
ST10
Hot Water Shrink Tank
VT400 / VT570 MAP Tray Sealers
Map Tray Sealers
VT109 Tray/Cup Sealer
Tray & Cup Sealer
BT800 / BT1000
Belt Type Vacuum Sealer
NZ Series Vacuum Nozzle
Nozzle Type Vacuum Packaging
CV1000 / CV1200
Continues Vacuum Packaging Machine
Double Chamber Series
Vacuum Pack Bags & More
SC680 / SC800
Single Chamber Vacuum Packaging
SC420 / SC520
Single Chamber Vacuum Packaging
TC420 / TC520
Table Top Vacuum Machine
TC350
Table Top Vacuum Machine
